Let's Design A Keyboard With Ergogen v4: Offline Ergogen, External Footprints, & Cases (Part 4)

units: # Proxy Spacing Variables kx: cx ky: cy # Padding Variables px: kx + 4 py: ky + 4 # Double Padding Variables dpx: kx + 8 dpy: ky + 8 points: ... outlines: raw: ... keys: ... board: ... xlBoard: - what: polygon operation: stack points: - ref: matrix_outer_num shift: [-0.5dpx,0.5dpy] - ref: matrix_ring_num shift: [-0.5dpx,0.5dpy] - ref: matrix_middle_num shift: [-0.5dpx,0.5dpy] - ref: matrix_middle_num shift: [0.5dpx,0.5dpy] - ref: matrix_inner_num shift: [0.5dpx,0.5dpy] - ref: matrix_inner_top shift: [0.5dpx,0.5dpy] - ref: mirror_matrix_inner_top shift: [0.5dpx,0.5dpy] - ref: mirror_matrix_inner_num shift: [0.5dpx,0.5dpy] - ref: mirror_matrix_middle_num shift: [0.5dpx,0.5dpy] - ref: mirror_matrix_middle_num shift: [-0.5dpx,0.5dpy] - ref: mirror_matrix_ring_num shift:…
